Technology
|
Projection System
|
3LCD Technology, RGB liquid crystal shutter
|
LCD Panel
|
0.55 inch with C2 Fine
|
|
Color Light Output
|
3,600 Lumen- 2,400 Lumen (economy) In accordance with IDMS15.4
|
White Light Output
|
3,600 Lumen - 2,400 Lumen (economy) In accordance with ISO 21118:2020
|
Resolution
|
XGA
|
Aspect Ratio
|
4:3
|
Contrast Ratio
|
16,000 : 1
|
Light source
|
Lamp
|
Lamp
|
UHE, 210 W, 6,000 h durability, 12,000 h durability (economy mode)
|
Keystone Correction
|
Auto vertical: ±30 °, Manual horizontal ±30 °
|
Colour Video Processing
|
10 Bits
|
2D Vertical Refresh Rate
|
100 Hz - 120 Hz
|
Colour Reproduction
|
Upto 1.07 billion colours
|
Optical
|
Throw Ratio
|
1.48 - 1.77:1
|
Zoom
|
Manual, Factor:1.2
|
Lens
|
Optical
|
Screen Size
|
30 inches - 300 inches
|
Projection Distance Wide/Tele
|
1.8 m - 2.17 m ( 60 inch screen ),
|
Projection Lens F Number
|
1.49 - 1.72
|
Projection Lens Focal Length
|
16.9 mm - 20.28 mm
|
Projection Lens Focus
|
Manual
|
Offset
|
8 : 1
|
Connectivity
|
Interfaces
|
USB 2.0-A, USB 2.0, VGA in, HDMI in, Cinch audio out, Wireless LAN IEEE 802.11b/g/n (optional)
|
Epson iProjection App
|
Ad-Hoc / Infrastructure
|
Advanced Features
|
Security
|
Kensington lock, Security bar, Wireless LAN unit lock, Password protection
|
3D
|
No
|
2D Colour Modes
|
Dynamic, Cinema, Presentation, sRGB, Blackboard
|
Other features
|
AV Mute Slide, Auto source search, Built-in speaker, Horizontal and vertical keystone correction, Long lamp life, Quick Corner, Split-Screen-Function
|
Video Color Modes
|
Blackboard, Cinema, Dynamic, Presentation, sRGB
|
General
|
Power consumption
|
286 Watt (Normal On-Mode), 327 Watt (Normal Peak-mode), 225 Watt (Eco Peak-Mode), 0.3 Watt (Energy saving standby)
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
Product dimensions
|
302 x 237 x 82 mm (Width x Depth x Height)
|
Product weight
|
2.5 kg
|
Noise Level
|
Normal:37 dB (A) - Economy:28 dB (A)
|
Supported Temperature
|
Operation 5° C - 35° C, Storage -10° C - 60° C
|
Supported Humidity
|
Operation 20% - 80%, Storage 10% - 90% If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.
|
Included Software
|
Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Management, Epson Projector Professional Tool
|
Options
|
Soft carry case, Wireless LAN unit
|
Loudspeaker
|
2 Watt
|
What's in the box
|
Computer cable, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User manual (CD), Warranty card
|
Room Type / Application
|
Home Office, Home Photo, Streaming, TV & Box sets
|
Positioning
|
Ceiling Mounted, Desktop
|
Colour
|
White
|
Other
|
Warranty
|
24 months Carry in, Lamp: 12 months or 1,000 h
|
Country of Origin
|
Country Of Origin
|
Philippines
|
